QL40-NEU

Neutron - Thermal Neutron

Measures Neutron porosity in counts per second

Request a Quote

Questions? Contact Sales

Description

The QL40-NEU neutron probe utilizes a He-3 thermal neutron detector. It measures Neutron porosity in counts per second, which can be directly related to the porosity of the formation. The probe has been carefully designed to maximize the detector sensitivity so that good results can be achieved with source strength of only 1 Curie. The source is carried in a specially designed shield and the probe itself is the source handling tool.

The QL40-NEU tool is stackable within the Quick Link (QL) product line or it can be run as a standalone tool. It can be run in any borehole environment.

Applications

  • Quantitative In-situ Porosity
  • Petrophysical Properties
  • Aquifer Quality and Delineation
  • Moisture Content of Unsaturated Matrix
  • Used with other logs, can detect gas zones and identify gas-liquid contacts
QL40-NEU — Neutron - Thermal Neutron — Measures Neutron porosity in counts per second

Technical Specifications

Operating Conditions

  • Borehole Fluid

    • Water
    • Mud
    • Dry

  • Casing

    • Uncased
    • PVC Borehole
    • Steel

  • Centralization

    • Non-Required

Features & Benefits

  • Improved thin bed resolution
  • Real-time Quantitative Porosity
  • Americium Beryllium Source
  • Operates on any standard wireline (Mono, 4, 7 conductor, or Coax)
  • Can be combined with other logging tools of the QL product line or operated as a standalone tool.

Specifications

  • Diameter: 40 mm (1.6 in.)

  • Length: 1.34 m (46 in.)

  • Weight: 5.5 Kg (12 lbs.)

  • Max. Temp.: 70ºC (158ºF)

  • Max. Pressure: 200 bar (2900 psi)

  • Sensor: He-3

  • Source-Detector Spacing: 35 cm / 13.77 in.

  • Source: 1- 3 Curie Am241Be

  • Measurement: Neutron Porosity (cps)

QL Stack Possibilities

  • QL40NEU + QL40GR (Gamma): Exploration, Petrophysical Properties
  • QL40NEU + QL40GR (Gamma) + QL40DEV (Deviation): Exploration, Borehole Deviation
  • QL40NEU + QL4SGR (Spectral Gamma) + QL40ELOG (Resistivity): Groundwater Suite tools, Quantitative Analysis, Lithology, Porosity Estimates
