19GR

Nano gamma

The slimmest downhole gamma probe at 19.05 mm

Request a Quote

Questions? Contact Sales

Description

The 19GR Nano Gamma is the slimmest downhole gamma probe in existence today. At only 19.05 mm (0.75 inches) in diameter, it can be used inside Geoprobe push tubes to collect lithological information in soils or other hard to reach zones. It is operated as a standalone pulse probe on the Matrix acquisition system.

The natural gamma probe measures the amount of gamma radiation occurring naturally within the formations crossed by a hole. Gamma rays are produced mainly by isotopes of potassium, thorium, and uranium. The gamma log is widely used in the groundwater and environmental industries to identify lithology and perform containment analyses.

Applications

  • Bed boundary analysis
  • Facies changes
  • Coarsening/ Fining Sequences
  • Identify Clay Aquitards
  • Aquifer Thickness
  • Uranium Concentration

Downloads

19GR — Nano gamma — The slimmest downhole gamma probe at 19.05 mm

Technical Specifications

Operating Conditions

  • Borehole Fluid

    • Water
    • Mud
    • Dry

  • Casing

    • Uncased
    • PVC Borehole
    • Steel

  • Centralization

    • Non-Necessary

Features & Benefits

  • Versatile, ubiquitous probe which functions with a wide range of applications and borehole conditions.
  • Fits inside small push tubes and other non-standard piping.
  • Exceptionally small diameter and easy to use.
  • Mount Sopris manufactures more natural gamma and spectral tools than any other slimline manufacturer in the world today.

Specifications

  • Diameter: 19.05 mm (0.75 in.)
  • Length: 48.3 cm (19.00 in.)
  • Length with weight sub: 58.4 cm (23.00 in.)
  • Weight: 496 g (1.09 lbs)
  • Weight with weight sub: 743 g (1.64 lbs)
  • Max. Temp.: 50ºC (120ºF)
  • Max. Pressure: 100 bar (1450 psi)
  • Sensor CsI(Na) Crystal: 1.05 x 7.62 cm (0.415 x 3.0 in)
  • Nominal Op. Voltage: 24 VDC
  • Nominal Op. Current: 74 mA
